Trimble SPS880 Extreme GPS GLONASS 902-928 MHz Base Or Rover

* Trimble SPS880 Extreme Base Or Rover Receiver w/ Options... [ID- X1781-L/T* ]
          - CMR Inputs
          - CMR Outputs
          - RTCM Inputs
          - RTCM Outputs
          - Data Collector
          - Bluetooth
          - L2CS
          - UHF Transmit
          - L5
          - Enable GLONASS
          - Software Version 4.19
          - Boot Version 3.55
          - Radio Version 4.10f
          - 902-928 MHz Radio Module P/N: 57880-90
          - Serviced By A Trimble Authorized Service Center
* Li-Ion Battery Charger w/ AC Adapter
* Antenna
* Battery Pack
* AC Adapter/Charger
* User Manual On Cd-ROM
* Carrying Case (G)

Trimble SPS880 Extreme GPS Smart Antenna

Highly portable, flexible GPS receiver
The Trimble® SPS880 Extreme Smart GPS Antenna is the simple solution to all your site measurement and stakeout applications. The ability to receive L2C code, L5 carrier signal, and GLONASS means you have a future-proof receiver, able to utilize new satellites as they are launched. The rugged, smart antenna includes an integrated radio, GPS receiver, GPS antenna, and battery in a single, lightweight housing designed for maximum portability, quick setup, and optimal flexibility.

The SPS880 Extreme Smart GPS Antenna offers contractors an easy-to-use, wide area measurement system for a variety of site preparation and grade checking applications. It can be used either as a rover for site measurement and stakeout or as a base station to support site measurement and machine control operations. As a base station, the SPS880 Extreme takes little setup time and only requires a single keystroke each day to start up.

Features:

• Small, lightweight design – 1.35 kg (2.97 lb) (integrated radio, GPS receiver, GPS antenna, and battery); 3.71 kg (8.18 lbs) complete system weight (rover including controller and rod)
• The quick setup, high mobility base or rover receiver, is ideal for large jobsites as a rover, and for working on multiple jobsites on a daily or weekly basis
• 72-channel L1/L2/L2C/L5/GLONASS receiver
• Performs all site measurement and stakeout operations within the operating range of the radio
• Internal, removable, smart Lithium-ion battery provides up to 5.5 hours GPS rover operation per battery
• Bluetooth® wireless technology for cable free, no hassle base or rover operation
• Simple keypad with on/off key and LED indicators for power, radio, and satellite tracking
• 20 Hz update rate, which allows measurement from a moving chassis, for example mounted on a site supervisor’s vehicle for increased efficiency on large jobsites
• Full base and rover interchangeability
• Unrestricted range
• Operates within a VRS™ network for conventional base station-free rover capability
• Integrated transmit radio with unlimited range
• Receives L2C code, L5 carrier signal , and GLONASS for future proof investment as well as for improved satellite coverage in harsh GPS environments
• AutoBase functionality enables startup with a single button push upon subsequent visits to a site

Specifications:

General
Keyboard and display	On/Off key for one button start up
LED indicators	For satellite tracking, radio link reception and power monitoring
Receiver type	Fully-integrated “Smart” GPS antenna
Physical
Dimensions (W x H)	19 cm (7.5 in) × 11.2 cm (4.4 in) including connectors
Weight	1.35 kg (2.97 lb) receiver only including internal battery 3.71 kg (8.18 lbs) complete system weight (rover including controller and pole)
Temperature	Operating:  –40 °C to +65 °C (–40 °F to +149 °F) Storage: –40 °C to +75 °C (–40 °F to +167 °F)
Humidity	100%, condensing
Waterproof	IPX7 for submersion to depth of 1 m (3.3 ft)
Shock and vibration	Tested and meets the following environmental standards: Shock – non-operating: Designed to survive a 2 m (6.6 ft) pole drop onto concrete Shock – operating: To 40 G, 10 msec, sawtooth Vibration: MIL-STD-810F, FIG.514.5C-1
Performance
Measurements	Advanced Trimble Maxwell™ 5 Custom GPS chip Trimble R-Track ™ technology for tracking the new L2C Civil Signal, L5 Signal for GPS modernization, and GLONASS High-precision multiple correlator for L1, L2, and L5 pseudo-range measurements Unfiltered, unsmoothed pseudo-range measurements data for low noise, low multipath error, low time domain correlation and high dynamic response Very low noise L1, L2, and L5 carrier phase measurements with <1 mm precision in a 1 Hz bandwidth L1, L2, and L5 signal-to-noise ratios reported in dB-Hz Proven Trimble low elevation tracking technology 72 channels L1 C/A Code, L2C, L5C, L1/L2/L5 GLONASS Full Cycle Carrier SBAS (WAAS/EGNOS/MSAS)
Code differential GPS positioning	Horizontal accuracy: ±(0.25 m + 1 ppm) RMS Vertical accuracy: ±(0.5 m + 1 ppm) RMS
SBAS	Horizontal accuracy: Typically <1 m (3.28 ft) Vertical accuracy: Typically <5 m (16.40 ft)
Real-Time Kinematic (RTK) positioning	Horizontal accuracy: ±(10 mm + 1 ppm) RMS, ±(0.032 ft +1 ppm) RMS Vertical accuracy: ±(20 mm + 1 ppm) RMS, ±(0.065 ft +1 ppm) RMS
Initialization time	Regular RTK operation with base station: Single/Multi-base minimum 10 seconds + 0.5 times baseline length in km, up to 30 km
RTK operation with Scalable GPS infrastructure	Typically <30 seconds anywhere within coverage area (Max and Extreme options only) Initialization reliability: >99.9%
Electrical
Power	11 to 28 V DC external power input with over-voltage protection on Port 1 (7-pin Lemo)
Battery	Rechargeable, removable 7.4 V, 2.4 Ah Lithium-ion battery in internal battery compartment.
Power consumption	<2.5 W, in RTK mode with internal radio
Rover operation times on internal battery	450 MHz systems: Receive only 5.5 hours; varies with temperature 900 MHz systems: Receive only 5.5 hours: varies with temperature
Base station operation times on internal battery	450 MHz systems: Approximately 4.2 hours; varies with temperature 900 MHz systems: Approximately 5.5 hours; varies with temperature
Certification	Class B Part 15, 22, 24 FCC certification, Canadian FCC, CE mark approval and C-tick approval
Communications
Communications	Port 1 – 3-wire RS-232 (7-pin 0-Shell Lemo) Port 2 – Full RS-232 (9-pin D-sub) Fully-integrated, fully-sealed 2.4 GHz Bluetooth
Integrated radios	Fully-integrated, fully-sealed internal 450 MHz, Tx/Rx Fully-integrated, fully-sealed internal 900 MHz, Rx only
Receiver position update rate	1 Hz, 2 Hz, 5 Hz, 10 Hz, and 20 Hz positioning
Correction data input	CMR, CMR+, RTCM 2.0–RTCM 2.3, RTCM 3.0
Correction data output	CMR, CMR+, RTCM 2.0–2.3
Data outputs	NMEA, GSOF. RT17
