Leica TCRA1101 Plus 1" Auto Target Motorized Auto Target Total Station Total Station

* Leica TCRA 1101 Plus 1" Motorized Auto Target Total Station w/ Options... [ID- X1581-L/T*]
         - Automatic Target Recognition
         - Motorized
         - Reflectorless Measurement
         - Calibrated By A Leica Authorized Service Center
* Leo LT208V | GRL111 Battery Charger w/  AC Adapter
* Lens Protector Hood
* PC-ATA Flash Card P/N: FA008
* Leica Diagonal Eye Piece
* Hard Carrying Case

Leica TCRA 1101 Plus 1" Total Station

Sophisticated functions for demanding users
The TPS1100 Professional Series was designed to provide practical solutions to make surveying processes simple, efficient and productive. The TPS1100 Professional Series includes a wide variety of practical, automated functions to achieve the highest degree of efficiency within the shortest period.

One of the many examples is the ATR, the Automatic Target Recognition. With ATR, the instrument fine to points  targets by itself. Manual  targeting is no longer required. Surveys are made faster and easier, leaving more time to carefully record all significant data.

Flexible in everyday applications
TPS1100 Professional Series high-end surveying instruments offer a high degree of flexibility. The easy-to-read, simple user interface and professional programming environment invite you to configure the instrument  to meet your individual requirement and personal preferences. The modular system assures a large  variety of available models and options to meet  the varying demands and requirements.

Software for efficient data acquisition
Information technologies and surveying are growing closer together. This is evident in the range of software available for the TPS1100 Professional Series. The software programs are tailored to acquire and process data with the instrument and then to transfer the data from the instrument to a computer.

Leica’s proven know-how
All the quality and performance that made the previous Leica total stations so successful are included in the new TPS1100 Professional Series. Plus the latest technological developments: light weight design, easy-to-use interface and the highest quality at an excellent price/performance ratio.


Specifications:

Angle measurement
Accuracy Hz, V (ISO 17123-3):	1.5’’ (0.5 mgon)
Display resolution:	1’’ (0.1 mgon)
Method	absolute, continuous, diametric
Distance measurement (IR)
Range (average atmospheric conditions)
Round prism (GPR1):	3000m / 9,800 ft
360° reflector (GRZ4):	1500m / 4,900 ft
Mini prism:	1200m / 3,900 ft
Reflective tape (60 mm x 60 mm):	250 m / 820 ft
Shortest measurable distance:	0.2 m to round prism (GPR1) / 1.5 m to a 360° reflector
Accuracy (ISO 17123-4) / Measuring time
Standard mode:	2 mm + 2 ppm / 1.0 sec
Fast mode:	5 mm + 2 ppm / 0.5 sec
Tracking mode:	5 mm + 2 ppm / 0.3 sec
Fast mode tracking:	10 mm + 2 ppm / < 0.15 sec
Display resolution:	1 mm
Method	Principle of phase measurement (coaxial, invisible infrared laser)
Reflectorless and Long Range distance measurement (RL)
Range (average atmospheric conditions)
Reflectorless (extended range):	170 m / 550 ft (Kodak Gray Card, white side)
Reflectorless (standard range):	80 m / 260 ft (Codak Gray Card, white side)
Shortest measurable distance:	1.5 m
Long Range on to round prism (GPR1):	1000 m – 5000 m
Accuracy (ISO 17123-4) / Measuring Time
Reflectorless (standard mode):	3 mm + 2 ppm / typ. 3–6 sec, max. 12 sec
Reflectorless (tracking mode):	10 mm + 2 ppm / typ. 3–6 sec, max. 12 sec
Laser dot size:	5 mm + 2 ppm / typ. 2.5 sec, max. 8 sec
Laser dot size
At 50 m:	approx. 10 mm x 20 mm
At 100 m:	approx. 15 mm x 30 mm
At 200 m:	approx. 30 mm x 60 mm
Method	Principle of phase measurement (coaxial, visible red laser)
Motorized (M)
Maximum speed
Rotating speed:	50 gon / sec (45 deg / sec)
Automatic Target Recognition (ATR)
Range ATR mode / LOCK mode (average atmospheric conditions)
Round prism (GPR1):	1000 m / 800 m (3300 ft / 2600 ft)
360° reflector (GRZ4):	600 m / 500 m (1900 ft / 1600 ft)
Mini prism:	500 m / 400 m (1600 ft / 1300 ft)
Reflective tape (60 mm x 60 mm):	65 m / -- (200 ft / -- )
Shortest measurable distance:	1.5 m to 360° reflector (GRZ4)
Accuracy / Measuring Time
Distances < 300 m:	3 mm / 3 sec
Distances > 300 m:	5’’ / 3–4 sec
Maximum speed (LOCK mode)
Tangential (standard mode):	25 m / sec at 100 m
Tangential (tracking mode):	18 m / sec at 100 m
Radial (tracking mode):	4 m / sec
Method	Digital image processing (laser beam)
Electronic Guide Light (EGL)
Range (average atmospheric condition)
Work range:	5 m – 150 m / 15 ft – 500 ft
Accuracy
Positioning accuracy:	5 cm to 100 m
General data
Compensator
Setting range:	4’ (0.07 gon)
Setting accuracy:	0.5’’ (0.2 mgon)
Method:	centralized dual axis compensator
Level
Sensitivity of circular level:	6’ / 2 mm
Display resolution electronic level:	1’’ (0.1 mgon)
Telescope
Magnification:	30x
Free aperture of objective:	40 mm
Field of view:	1°30’ (1.66 gon) / 2.7 m at 100 m
Focussing:	1.7 m to infinite
Control unit
Display:	8 lines with 32 characters 256*64 pixels, graphic LCD
Keyboard:	30 keys (6 function keys, 12 alphanumeric keys)
Angle display:	360°’ ’’, 360° (decimal), 400 gon, 6400 mil, V%
Distance display:	Meter, Int. Ft, Int. Ft/Inch, US Ft, US Ft/Inch
Number of Displays:	1 / 2 (optional)
Data storage
Memory card:	PCMCIA ATA Flash (16 MB) / PCMCIA SRAM (512 KB, 2 MB)
Number of data files:	18000 / 2 MB
Interface:	RS232
Laser plummet
Accuracy:	Deviation from the plumb line 1.5 mm (2 sigma) at 1.5 m
Point diameter:	2.5 mm at 1.5 m
Endless drive
Number of drives Hz / V:	1 / 1
Steps:	infinite
Battery
Type:	Nickel Metal Hydride (NiMH)
Voltage:	6 V
Capacity (GEB121):	3.6 Ah
Number of measurements:	400 – 600
Weight
Instrument:	4.7 – 4.9 kg (10.4 –10.8 Ibs)
Battery (GEB121):	0.4 kg (0.8 Ibs)
Tribrach (GDF121):	0.8 kg (1.7 Ibs)
Working environment
Working temperature range:	–20°C to +50°C / –4°F to +122°F
Storage temperature range:	–40°C to +70°C / –40°F to +158°F
Dust/water (IEC 60529):	IP54
Humidity:	max. 95% non-condensing
